ASME SA 537 CL.1 PLATES
Our company Diamond alloys Inc comes in some admirable and prestigious companies over the entire world in our field. If the person is seeking and searching for some excellent quality plates to use under various applications and many other kinds of the process of the industries then our company’s fabricated SA 537 CL.1 Steel Plates is one of the best choices. The plates fabricated by our company are ideal for the construction process of various machinery and different kinds of other artefact used in the company or at the workplace. These kinds of class 1 plates produced by our company are one of the most popular plates amongst the various kinds of engineers.
SA537 STEEL PLATES, A537 CLASS 1 STEEL PLATE, ASME SA537 CL.1 PRESSURE VESSEL PLATES, SA537 CLASS 1 STEEL PLATES SUPPLIER IN MUMBAI, SA537 CLASS 1 BQ PLATES STOCKIST, ASTM A537 CL.1 BOILER QUALITY STEEL PLATES STOCKIST IN MUMBAI, INDIA.
PRESSURE VESSEL A537 CL.1 STEEL PLATE, SA537 CL.1 INDUSTRIAL BOILER AND PRESSURE VESSEL STEEL PLATES, A537 HOT ROLLED PRESSURE VESSEL CLASS 1 STEEL PLATE, A537 LOWER TEMPERATURE CARBON STEEL CLASS 1 PLATES SUPPLIER & EXPORTER.
Properties of SA 537 CL.1 PLATES and its applications –
The types of class 1 plates manufactured by our company are having a great demand in our field. These kinds of plates discovered by our company deliver an admirable resistivity to any kind of corrosive activity. Our company’s SA 537 CL.1 PLATES are highly repellent to numerous and enormous kinds of leakages. The inclination to tolerate the maximum pressure with the least amount of elongation is quite impressive and admirable for different kinds of usage in various kinds of industries. The service of these kinds of class 1 plates which is fabricated by our company is quite more if compared to any other company’s class 1 plates as the plates of our company can be used in any kind pressure vessels at ease.
Packaging and the documents delivered –
The packaging of the products which is fabricated keeping in mind the customer’s services we need to take be extra secured regarding the packaging of the product as a result of which the product is packed with complete security. The product is wrapped in the bubble wrap, gunny bags or in poly bags. After the wrapping process, the product is kept inside the wooden boxes and pallets or in the cartons to reach your doorsteps. All kinds of mandatory and required documents are kept in the package along with the product to avoid any kind of inconvenience.
PEOPLE ALSO SEARCHED FOR A537 CL.1 PRESSURE VESSEL PLATES
sa537 steel plate, sa 537 pressure vessel cl.1 steel plate stockists in india, a537 class 1 hr pressure vessel plates manufacturers in mumbai india, a537 cl.1 boiler and pressure vessel steel plates stockists in mumbai, astm a537 class 1 steel plates, a537 cl.1 hot rolled boiler quality plates, astm a537 boiler vessel steel class 1 plate hardness, sa 537 cl.1 plates, sa537 cl.1 pressure vessel carbon steel plates supplier in india, a537 cl.1 industrial steel plates specifications, asme sa537 cl.1 pressure vessel plates, sa537 class 1 pressure vessel steel plates price list, astm a537 class 1 bq plates properties, a537 class 1 low temperature carbon steel boiler quality plates equivalent grade, a537 cl.1 steel plates for boilers and pressure vessels manufacturers, sa537 hot rolled class 1 steel plate stockist in mumbai, a537 class 1 carbon steel plates in mumbai, sa537 class 1 boiler and pressure vessel steel plates pdf, a537 cl.1 boiler plates suppliers in india, a537 class 1 boiler quality plates prices, a537 hot rolled boiler class 1 steel plate chemical composition.
Grade |
ASME SA 537 CL.1 Boiler and Pressure Vessel Steel Plates |
Width |
1000mm-4500mm |
Thickness |
5mm-150mm |
Length |
3000mm-18000mm. |
Supply Condition |
As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
Impact tested |
-52° C |
Tempering |
Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
Applications |
Used for Boilers and Pressure Vessels Application. |
Process of Manufacturing |
Hot-Rolled (HR) |
CHEMICAL COMPOSITION OF A537 BQ CL.1 STEEL PLATES
C |
Mn |
P |
S |
Si |
Cr |
Cu |
Ni |
Mo |
≤ 40 mm |
> 40 mm |
0.24 max |
0.70/1.35 |
1.00/1.60 |
0.035 |
0.035 |
0.15/0.50 |
0.025 |
0.35 |
0.25 |
0.080 |
MECHANICAL PROPERTIES OF BOILER QUALITY STEEL PLATES
Grade |
Heat Treatment |
Yield (MPa) |
Tensile (MPa) |
Elongation |
Thickness |
A50mm |
A200mm |
SA537 Class 1 |
Normalized |
345 |
485/620 |
22% |
18% |
≤ 65 |
310 |
450/585 |
22% |
18% |
> 65 ≤ 100 |
EQUIVALENT GRADE OF A537 CLASS 1 BOILER PLATES
Steel Grade |
JIS |
Germany |
ASTM/ASME |
G3115 |
DIN17155 |
A537 / SA537 |
SPV36 |
19Mn5 |
PRICE LIST OF ASME SA537 CL.1 BOILER AND PRESSURE VESSEL PLATES
SA537 CL.1 Industrial Pressure Vessel Plate
US $800-3000 / Metric Ton( FOB Price)
Hot Rolled A537 Class 1 Steel Plates
US $605-629 / Metric Ton( FOB Price)
ASTM A537 CL.1 Boiler Quality Plates
US $800-4000 / Metric Ton( FOB Price)
SA537 Class 1 Lower-Temperature Steel Plates
US $500-800 / Metric Ton( FOB Price)
Export Quality ASME SA537 CL.1 Carbon Steel Plate
US $560-670 / Ton( FOB Price)
A537 Class 1 HR BQ Plates
US $500-900 / Ton( FOB Price)
WE OFFERS FOLLOWING PROCESSING FOR ASTM A537 HOT ROLLED BOILER CL.1 STEEL PLATE
Cutting,
Forming Drilling / Machining,
Grinding,
Testing
APPLICATIONS OF ASTM A537 HOT ROLLED PRESSURE VESSEL CLASS 1 STEEL PLATES
Machine building,
Pylons and other architectural structures,
Lifting and mobile equipment,
Construction of bridges,
Wearing plates,
Framework structures,
Crane booms,
Rail cars,
Stone or iron chutes,
Truck frames,
Containers,
Vehicles and transport equipment,
Steel constructions,
Anti drill plates such as security doors, shot blasting
equipment and tumbling machine.
