Diamond Alloys are the leading supplier and exporter of S355JR+N PLATES that are being made using qualitative material as well as the knowledge of experienced professionals. The plates are used in various industries and applications due to their varying features and properties. You can easily buy these plates at competitive or cost-effective rates from us. Being one of the reputed manufacturers and supplier of these plates, we make sure all our products are supplied to customers as per their demand. We are completely aimed to provide our customers with a high quality of products so that they can be easily used in a wide range of applications worldwide. The plates are available in different shapes, sizes, forms, and dimensions. Our qualified professionals have years of experience hence they make sure all the manufacturing process is done properly and using high quality of the material.
These plates are known with the standard designation as EN 10025: 2004 and S355 is useful structural grade steel that has a minimum strength of 355 N/mm2. It is being widely used in structural construction and engineering industries and offers high tensile and yield strength with a comprehensive range of treatments and test options. These tests ensure that it is excellent steel that can be used for various projects.
The S355 is basically offer minimum strength with JR term that confirms that the steel undergoes longitudinal chary impact testing at room temperature of 27J. The grade is considered excellent for manufacturing high quality of plates for a diverse range of applications.
| EN 10025-2 | Germany DIN 17100 | UNI | JIS | BS | ||
| S355JR+N | 1.0045 | St 52.3 | 1.0570 | Fe510D | SS490/SM490A | 50B |
These S355JR+N PLATES are manufactured using premium and top-notch quality of raw material as per the international quality standards. These plates are made as per the demand and requirement of customers for their application. Therefore, each and every material is well inspected and tested so that they can provide their best in the respective areas of working.
The material is of high quality and offers the best performance; in addition to the raw material latest machines and tools are used for creating high quality and comprehensive range of plates in different shapes and sizes.
The plates manufactured by us exhibit various features and properties that help customers know the actual quality of the product. The features include high tensile strength, corrosion and oxidation resistance, formability, workability, durability and long service life. All these features make these steel plates high in demand for a wide range of applications.
These two processes are considered important for the manufacturer as well as customers as this helps us know whether the manufactured product is of high quality or not. Therefore, we conduct several tests and inspections that help in order to check the quality and performance of these plates. The tests include high tensile strength test, hardness test, pitting resistance test, positive material identification test, and flaring test.
There are some more tests done like flattening test, third-party inspection, visual inspection, chemical composition analysis and more. The entire testing process is done under different temperatures and environments so as to check its performance. For all these tests various documents are also provided by the customers such as raw material test certificate, IGC test certificate, third-party inspection report, visual inspection report etc.
At last, when all the tests are done, these S355JR+N PLATES are packed in a high quality of packaging material that helps prevent rust and other unconditional damages until these plates are sent to their respective customers worldwide.
So, if you are also in need to buy these plates for your industrial applications then buy it from Diamond Alloy online at a competitive price now!
| Item | S355JR+N - Offshore & Structural Steel Plate |
|---|---|
| Thickness | 5mm-150mm |
| Width | 1000mm-4500mm |
| Length | 3000mm-18000mm or as custom’s request |
| Material | En 10025-2 Steel Plate, S355JR+N Steel Plate |
| Technique | hot rolled |
| Standard | EN 10025-2:2004 |
| Grade | C | Mn | Si | P | S | N | Cu | CEV |
| S355JR+N | 0.24 max. | 1.6 max. | 0.55 max. | 0.04 max. | 0.04 max. | 0.012 max. | 0.55 max. | 0.47 max. |
| Grade | Thickness (mm) | Min Yield (Mpa) | Tensile (Mpa) | Elongation (%) | Min Impact Energy | |
| S355JR+N | 8mm-100mm | 315-355 Mpa | 450-630 Mpa | 18-20% | 20 | 27J |
| 101mm-200mm | 285-295 Mpa | 450-600 Mpa | 18% | 20 | 27J | |
| 201mm-400mm | 275 Mpa | - | 17% | 20 | 27J | |
s355jr+n plate mechanical properties, s355jr+n plate specifications, s355jr+n structural steel hot rolled plate, s355jr+n hot rolled plate, s355jr+n plate sizes, s355jr+n, s355jr+n plates in mumbai, s355jr+n equivalent, s355jr+n plates in india, high quality s355jr+n steel plates, s355jr+n plate properties, s355jr+n plate stockholder in india, s355jr+n plate weight, s355jr+n equivalent grade, s355jr+n plate stockists in mumbai, s355jr+n plate supplier in mumbai, s355jr+n plate manufacturers in mumbai, s355jr+n plate stockists in india, s355jr+n plate chemical composition, hot rolled s355jr+n structural steel plate, s355jr+n pdf, s355jr+n plates dealer in mumbai, s355jr+n plate stockholder in mumbai, s355jr+n plates manufacturer in india, s355jr+n material plate, s355jr+n plate thickness, s355jr+n plate prices, s355jr+n hr structural steel plate, s355jr+n plate distributor, s355jr+n plate exporter in india, en 10025-2:2004 s355jr+n plate traders in mumbai, s355jr+n plate in india, din en 10025-2 s355jr+n non-alloy structural steel plate, plate grade s355jr+n, s355jr+n plate exporters in mumbai, hot rolled s355jr+n plate, s355jr+n plate hardness, s355jr+n plate price list, s355jr+n plate suppliers in india.
Cutting
Forming Drilling / Machining
Grinding
Testing
Machine building
Pylons and other architectural structures
Lifting and mobile equipment
Construction of bridges
Wearing plates
Framework structures
Crane booms
Rail cars
Stone or iron chutes
Truck frames
Containers
Vehicles and transport equipment
Steel constructions
Anti drill plates such as security doors, shot blasting equipment and tumbling machine
