S890QL PLATES
Diamond Alloys inc is a well-known manufacturer, supplier, exporter and stockist of S890QL Plate in Mumbai, India. Dillimax 890T is a high strength quenched and tempered steel with a fine grain structure. The yield strength is 890 MPa for the thinner plates, reducing as the plates get thicker.
S890QL Structural Steel Plate, S890QL High Strength Steel Plates, S890QL High Strength Hot Rolled Plates Exporters, Dillimax S890QL Plates, S890QL Plates Suppliers and Stockists in India.
EN-10025 S890QL High Strength Structural Steel Plate, S890QL High Strength Hot Rolled Plates Exporters, S890QL Industrial High Strength Steel Plates, ASTM A514 Grade S890QL High Strength Steel Plates Stockholder, S890QL High Strength Structural Steel Plate Supplier in Mumbai, India.
S890QL PLATES
The key benefit of S890QL Steel Plates is that enables a significant amount of weight to be saved in the structure which means reduced fabrication costs. S890QL Plates offer exceptional strength-to-weight ratio which helps to build bridges and sea-links, dependable for load-bearing. Their solid bodies bear heavy trucks and cars atop the bridge. Trailers, agricultural, mining and earth moving equipment, etc.
These EN 10025 S890QL Steel Plate are also known as High Strength Quenched and Tempered Steel Plate, High Yield Quenched and Tempered Steel Plate, High Strength Low Alloy Steel Plate, High Strength Structural Steel Plate, High Yield Structural Steel Plate, HSLA, etc. EN 10025 S890QL Steel Plate is used in applications such as cranes (mobile and loader), aerial platforms, and load handling equipment, bridges, and special containers. These S890QL Plates are available in different shape size and thickness according to the needs of our customers and also available in customized specifications at affordable prices.
S890QL Steel Plates Specification :
| Grade : |
S890QL EN10025-6:2004, DILLIMAX 890, WELDOX 900, S890QL, E890, JFE HITEN |
| Item : |
High Yield Strength Steel Plates |
| Thickness : |
3 mm to 300 mm |
| Width : |
2000 mm, 2500 mm, 3000 mm |
| Length : |
Up to 12000 mm long |
S890QL structural Plates Chemical Composition
| C |
Si |
Mn |
P |
S |
B |
Cr |
Cu |
Mo |
| 0.20 |
0.80 |
1.70 |
0.020 |
0.010 |
0.005 |
1.50 |
0.50 |
0.70 |
| N |
Nb* |
Ni |
Ti* |
V* |
Zr* |
|
|
|
| 0.015 |
0.06 |
2.0 |
0.05 |
0.12 |
0.15 |
|
|
|
S890QL High tensile Plates Mechanical Properties
| Plate Thickness |
Yield Strength |
Tensile Strength |
Elongation |
Impact Strength |
| mm |
ReH (MPa) |
Rm (MPa) |
A5 % minimum |
J, Minimum |
| 3 to 50 |
890 |
940 - 1100 |
11 |
30 @ -40º C |
| > 50 to 100 |
830 |
880 - 1100 |
11 |
30 @ -40º C |
S890QL Equivalent grades
| GRADE |
1.8983 |
|
|
| STANDARDS |
WERKSTOFF |
GOST |
IS |
| COUNTRY |
GERMANY |
RUSSIA |
INDIA |
WE OFFERS FOLLOWING PROCESSING FOR QUEND 700 SHEETS & PLATES
Cutting,
Forming Drilling / Machining,
Grinding,
Testing
APPLICATIONS OF QUEND 700 PLATES
Machine building,
Pylons and other architectural structures,
Lifting and mobile equipment,
Construction of bridges,
Wearing plates,
Framework structures,
Crane booms,
Rail cars,
Stone or iron chutes,
Truck frames,
Containers,
Vehicles and transport equipment,
Steel constructions,
Anti drill plates such as security doors, shot blasting
equipment and tumbling machine.
